Ambient temperature | -25°C~ +55°C |
Humidity | ≤90% |
Flow rate | 5~60L/min or 5~90L/min |
Nozzle | Auto shut-off |
Suction distance | 6m(Vertical), 50m(horizontal) |
Accuracy | ±0.30% |
Repeating tolerance | ≤0.15% |
Hose | 3m(low hang), 4.5m(high hang) |
Inlet pressure | ≥54kPa |
Outlet pressure | ≤0.3MPa |
Voltage | 110V/220V/380V (50/60Hz) |
Power | 1HP(0.75kw) |
Noise | ≤80dB(A class) |
Unit price range | 0.01~999.99 |
Single volume range | 0.01~999999.99 |
Accumulative volume range | 0.01~9999999999.99 |
Explosion-proof signal | ExdmbIIAT3 |
 | Filling Station Management System• FSMS adopts advanced technology and supply simple & convenient manager service. • It can connect totally 32 nozzles and realize real-time management. • System can control and monitor working conditions of all fuel dispensers & filling station clearly, such as setting parameters of machines, printing different data, monitoring storage of tank. |
Customized Design And Service• Dispenser outlook customized design • Station price sign customized design • Station canopy customized design • POS management system customized design |  |
 | Full Products Certificate Approval• OIML Standard Accuracy • Software Copyright • CNEX COC, SONCAP, ISO and CE |
Main Configuration• Novel and compact design • Electronic controller • High accurate meter pump filtering system to ensure clean fuel and dispenser long lifetime totalizer • Big LCD display board • Metal keyboard • Breakaway swivel • Emergency stop button • Integrated receipt printer LED rolling display • Media player and TV |  |
